Hex & D-Bore Shaft Collars

Ruland manufactures standard shaft collars with hex and d-bore profiles for proper mating with the appropriate shaft. Hex bore collars allow for added holding power and higher torque capabilities if being used in positive drive applications. D-bore collars are designed for use with d-shafting. They are a better option than set screw shaft collars as they do not mar the shaft, have higher holding power, and are indefinitely adjustable. Ruland manufactures hex and d-bore shaft collars in 1215 lead-free steel with a proprietary black oxide finish and 303 stainless steel. Hex collars are also available in high-strength 2024 aluminum for lightweight applications. D-bore shaft collars available in bore sizes from 1/4" to 1" and hex bore collars from 3/8" to 1/2".

Products

Items 1-24 of 72

Set Ascending Direction Set Descending Direction
  1. CLD-16-SS
    CLD-16-SS
    $75.61 ea
    Ruland CLD-16-SS, 1" D-Bore Shaft Collar, 303 Stainless Steel, One-Piece Clamp Style, 1 3/4" OD, 0.500" Width
  2. CLD-8-F
    CLD-8-F
    $33.61 ea
    Ruland CLD-8-F, 1/2" D-Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  3. SP-8HX-A
    SP-8HX-A
    $23.31 ea
    Ruland SP-8HX-A, 1/2" Hex Bore Shaft Collar, Aluminum, Two-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  4. SP-8HX-F
    SP-8HX-F
    $19.65 ea
    Ruland SP-8HX-F, 1/2" Hex Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  5. SPD-12-SS
    SPD-12-SS
    $74.36 ea
    Ruland SPD-12-SS, 3/4" D-Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 1 1/2" OD, 0.500" Width
  6. SPD-16-F
    SPD-16-F
    $50.82 ea
    Ruland SPD-16-F, 1" D-Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 1 3/4" OD, 0.500" Width
  7. SPD-16-SS
    SPD-16-SS
    $86.18 ea
    Ruland SPD-16-SS, 1" D-Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 1 3/4" OD, 0.500" Width
  8. SPD-8-F
    SPD-8-F
    $37.68 ea
    Ruland SPD-8-F, 1/2" D-Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  9. CL-8HX-SS
    CL-8HX-SS
    $25.63 ea
    Ruland CL-8HX-SS, 1/2" Hex Bore Shaft Collar, 303 Stainless Steel, One-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  10. CLD-12-F
    CLD-12-F
    $41.26 ea
    Ruland CLD-12-F, 3/4" D-Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 1 1/2" OD, 0.500" Width
  11. CLD-12-SS
    CLD-12-SS
    $65.29 ea
    Ruland CLD-12-SS, 3/4" D-Bore Shaft Collar, 303 Stainless Steel, One-Piece Clamp Style, 1 1/2" OD, 0.500" Width
  12. CLD-16-F
    CLD-16-F
    $45.43 ea
    Ruland CLD-16-F, 1" D-Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 1 3/4" OD, 0.500" Width
  13. CLD-4-F
    CLD-4-F
    $32.01 ea
    Ruland CLD-4-F, 1/4" D-Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 5/8" OD, 0.281" Width
  14. CLD-8-SS
    CLD-8-SS
    $53.57 ea
    Ruland CLD-8-SS, 1/2" D-Bore Shaft Collar, 303 Stainless Steel, One-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  15. SP-6HX-F
    SP-6HX-F
    $18.34 ea
    Ruland SP-6HX-F, 3/8" Hex Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 7/8" OD, 0.343" Width
  16. SPD-4-F
    SPD-4-F
    $36.02 ea
    Ruland SPD-4-F, 1/4" D-Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 5/8" OD, 0.281" Width
  17. SP-6HX-SS
    SP-6HX-SS
    $32.05 ea
    Ruland SP-6HX-SS, 3/8" Hex Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 7/8" OD, 0.343" Width
  18. SP-8HX-SS
    SP-8HX-SS
    $35.90 ea
    Ruland SP-8HX-SS, 1/2" Hex Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  19. SPD-12-F
    SPD-12-F
    $46.20 ea
    Ruland SPD-12-F, 3/4" D-Bore Shaft Collar, Black Oxide Steel, Two-Piece Clamp Style, 1 1/2" OD, 0.500" Width
  20. SPD-8-SS
    SPD-8-SS
    $61.00 ea
    Ruland SPD-8-SS, 1/2" D-Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 1 1/8" OD, 0.406" Width
  21. CL-6HX-F
    CL-6HX-F
    $10.35 ea

    Ruland CL-6HX-F, 3/8" Hex Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 7/8" OD, 0.343" Width

  22. CL-8HX-F
    CL-8HX-F
    $12.12 ea

    Ruland CL-8HX-F, 1/2" Hex Bore Shaft Collar, Black Oxide Steel, One-Piece Clamp Style, 1 1/8" OD, 0.406" Width

  23. SP-6HX-A
    SP-6HX-A
    $23.56 ea
    Ruland SP-6HX-A, 3/8" Hex Bore Shaft Collar, Aluminum, Two-Piece Clamp Style, 7/8" OD, 0.343" Width
  24. SPD-4-SS
    SPD-4-SS
    $49.88 ea
    Ruland SPD-4-SS, 1/4" D-Bore Shaft Collar, 303 Stainless Steel, Two-Piece Clamp Style, 5/8" OD, 0.281" Width
