Large jaw couplings are now being offered for bore sizes up to 1-3/4” or 45 mm and torque capacities of 2,655 in-lbs (300 Nm). These new large jaw couplings are designed for use in precision systems with high deceleration and acceleration curves, such as those found in semiconductor, solar, conveyor, and warehouse automation applications.
Pre-assembled modular mounting systems are designed for adjustability across many mounting applications. Conveyor mounting systems emphasize strict parallel installation using a flange-bolt base and a conveyor rail guide. Sensor mounting systems offer flexibility in a mounting application with adjustable or 90-degree connectors, two-way bases, and various mounting brackets. Both systems include stainless steel rods (with or without scale) from 100mm to 300mm in length, zinc clamping levers, and connectors that allow adjustment of the rods’ position.
Mountable shaft collars with face holes are designed to mate directly with components such as sprockets, pulleys, and metallic plates. Ruland manufactures them with drilled holes for mounting flexibility or threaded holes for the most secure connection between the collar and mated component. They are offered in steel, aluminum, and 303 stainless steel in bore sizes ranging from 3/8” to 2” and 10mm to 50mm.
International series shaft collars are offered in one and two-piece styles and feature inch bores with metric outer diameters, widths and DIN 12.9 socket headed cap screws. The use of metric screws with inch bores is especially useful when either retrofitting or designing equipment with inch shafts for worldwide use. The International series shaft collar is available in bore sizes from ¼” to 3” with outside diameters from 18mm to 108mm.
