Quick Clamping Shaft Collars

Ruland offers two types of quick clamping shaft collars that require no tools to be adjusted: the quick clamping shaft collar with a cam lever and the shaft collar with a clamping lever. Both are ideal for applications that require frequent setup changes or adjustments such as those found in packaging and printing.

The quick clamping shaft collar with a cam lever features a cam lever that sits flush with the outside diameter, allowing the shaft collar to be precisely adjusted by hand. It is best suited for light duty or low RPM applications. These collars are made from aluminum with a black anodized finish and have stainless steel hardware. They do not mar the shaft and are indefinitely adjustable. Bore sizes on the quick-clamping shaft collars with a cam lever range from 1/4" to 3" and 6mm to 75mm.

The shaft collar with a clamping lever is a combination of Ruland one-piece shaft collars and flat handle adjustable clamping levers. The stainless steel threaded stud on the adjustable clamping lever is used in place of standard collar hardware. When combined, the two parts create a quick release shaft collar with a ratcheting handle. Once the lever is installed in the shaft collar, users simply turn the lever until they meet their desired torque. Bore sizes range from 3/8” to 1 ½” and 11mm to 40mm.

About

with Cam Lever

Quick-clamping shaft collars are ideal for light duty or low-rpm applications that require frequent setup changes or adjustments. The handle sits flush with the outside diameter allowing the shaft collar to be precisely adjusted by hand without the need for tools. The quick-clamp shaft collar is made from aluminum and has a black anodized finish with stainless steel hardware. They do not mar the shaft and are indefinitely adjustable. Bore sizes range from 1/4" to 3" and 6mm to 75mm.

EXPLORE >>
with Cam Lever
with Clamping Lever

This Ruland bundle combines a one or two-piece shaft collar with a clamping lever to make a quick release shaft collar. The threaded stud on the adjustable clamping lever is used in place of standard collar hardware. When combined, the two parts create a shaft collar with a ratcheting handle that requires no tools to install, remove, or reposition and is ideally suited for packaging, printing, and other applications where frequent setup changes and adjustments are needed. Once the lever is installed in the shaft collar, users simply turn the lever until they meet their desired torque. Bore sizes range from 3/8” to 1 ½” and 11mm to 40mm. Collars are available in anodized aluminum, plain aluminum, 303 stainless steel, 316 stainless steel, steel, plastic, and zinc. The clamping lever is comprised of a black or orange die-cast zinc handle and a 303 stainless steel threaded stud.

EXPLORE >>
with Clamping Lever

Products

View as Grid Table

Items 1-24 of 960

Set Descending Direction
  1. Ruland LV-MCL-10E-AN
    LV-MCL-10E-AN
    Ruland LV-MCL-10E-AN, 5/8" One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 34mm OD, 13mm Width
  2. Ruland LV-MCL-10E-F, Shaft Collar with Lever
    LV-MCL-10E-F
    Ruland LV-MCL-10E-F, 5/8" One-Piece Shaft Collar with Clamping Lever, Steel Collar with Zinc Plated Lever, 34mm OD, 13mm Width
  3. Ruland LV-MCL-10E-P, Shaft Collar with Lever
    LV-MCL-10E-P
    Ruland LV-MCL-10E-P, 5/8" One-Piece Shaft Collar with Clamping Lever, Plastic Collar with Zinc Plated Lever, 34mm OD, 13mm Width
  4. Ruland LV-MCL-10E-SS, Shaft Collar with Lever
    LV-MCL-10E-SS
    Ruland LV-MCL-10E-SS, 5/8" One-Piece Shaft Collar with Clamping Lever, 303 SS Collar with Zinc Plated Lever, 34mm OD, 13mm Width
  5. Ruland LV-MCL-11-A, Shaft Collar with Lever
    LV-MCL-11-A
    Ruland LV-MCL-11-A, 11mm One-Piece Shaft Collar with Clamping Lever, Aluminum Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  6. Ruland LV-MCL-11-AN, Shaft Collar with Lever
    LV-MCL-11-AN
    Ruland LV-MCL-11-AN, 11mm One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  7. Ruland LV-MCL-11-F, Shaft Collar with Lever
    LV-MCL-11-F
    Ruland LV-MCL-11-F, 11mm One-Piece Shaft Collar with Clamping Lever, Steel Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  8. Ruland LV-MCL-11-SS, Shaft Collar with Lever
    LV-MCL-11-SS
    Ruland LV-MCL-11-SS, 11mm One-Piece Shaft Collar with Clamping Lever, 303 SS Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  9. Ruland LV-MCL-12-A, Shaft Collar with Lever
    LV-MCL-12-A
    Ruland LV-MCL-12-A, 12mm One-Piece Shaft Collar with Clamping Lever, Aluminum Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  10. Ruland LV-MCL-12-AN, Shaft Collar with Lever
    LV-MCL-12-AN
    Ruland LV-MCL-12-AN, 12mm One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  11. Ruland LV-MCL-12-F, Shaft Collar with Lever
    LV-MCL-12-F
    Ruland LV-MCL-12-F, 12mm One-Piece Shaft Collar with Clamping Lever, Steel Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  12. Ruland LV-MCL-12-P, Shaft Collar with Lever
    LV-MCL-12-P
    Ruland LV-MCL-12-P, 12mm One-Piece Shaft Collar with Clamping Lever, Plastic Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  13. Ruland LV-MCL-12-SS, Shaft Collar with Lever
    LV-MCL-12-SS
    Ruland LV-MCL-12-SS, 12mm One-Piece Shaft Collar with Clamping Lever, 303 SS Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  14. Ruland LV-MCL-12-ST, Shaft Collar with Lever
    LV-MCL-12-ST
    Ruland LV-MCL-12-ST, 12mm One-Piece Shaft Collar with Clamping Lever, 316 SS Collar with Zinc Plated Lever, 28mm OD, 11mm Width
  15. Ruland LV-MCL-12E-AN, Shaft Collar with Lever
    LV-MCL-12E-AN
    Ruland LV-MCL-12E-AN, 3/4" One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 40mm OD, 15mm Width
  16. Ruland LV-MCL-12E-F, Shaft Collar with Lever
    LV-MCL-12E-F
    Ruland LV-MCL-12E-F, 3/4" One-Piece Shaft Collar with Clamping Lever, Steel Collar with Zinc Plated Lever, 40mm OD, 15mm Width
  17. Ruland LV-MCL-12E-P, Shaft Collar with Lever
    LV-MCL-12E-P
    Ruland LV-MCL-12E-P, 3/4" One-Piece Shaft Collar with Clamping Lever, Plastic Collar with Zinc Plated Lever, 40mm OD, 15mm Width
  18. Ruland LV-MCL-12E-SS, Shaft Collar with Lever
    LV-MCL-12E-SS
    Ruland LV-MCL-12E-SS, 3/4" One-Piece Shaft Collar with Clamping Lever, 303 SS Collar with Zinc Plated Lever, 40mm OD, 15mm Width
  19. Ruland LV-MCL-13-A, Shaft Collar with Lever
    LV-MCL-13-A
    Ruland LV-MCL-13-A, 13mm One-Piece Shaft Collar with Clamping Lever, Aluminum Collar with Zinc Plated Lever, 30mm OD, 11mm Width
  20. Ruland LV-MCL-13-AN, Shaft Collar with Lever
    LV-MCL-13-AN
    Ruland LV-MCL-13-AN, 13mm One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 30mm OD, 11mm Width
  21. Ruland LV-MCL-13-F, Shaft Collar with Lever
    LV-MCL-13-F
    Ruland LV-MCL-13-F, 13mm One-Piece Shaft Collar with Clamping Lever, Steel Collar with Zinc Plated Lever, 30mm OD, 11mm Width
  22. Ruland LV-MCL-13-SS, Shaft Collar with Lever
    LV-MCL-13-SS
    Ruland LV-MCL-13-SS, 13mm One-Piece Shaft Collar with Clamping Lever, 303 SS Collar with Zinc Plated Lever, 30mm OD, 11mm Width
  23. Ruland LV-MCL-14-A, Shaft Collar with Lever
    LV-MCL-14-A
    Ruland LV-MCL-14-A, 14mm One-Piece Shaft Collar with Clamping Lever, Aluminum Collar with Zinc Plated Lever, 30mm OD, 11mm Width
  24. Ruland LV-MCL-14-AN, Shaft Collar with Lever
    LV-MCL-14-AN
    Ruland LV-MCL-14-AN, 14mm One-Piece Shaft Collar with Clamping Lever, Anodized Aluminum Collar with Zinc Plated Lever, 30mm OD, 11mm Width
