| Dimension | |||
|---|---|---|---|
|
Bolt Diameter DB |
12 mm |
Bolt Length LB |
19 mm |
|
Counterbore 1 Diameter K1 |
8.5 mm |
Counterbore 2 Diameter K2 |
5.5 mm |
|
Overall Length L1 |
38 mm |
Hub Length LH |
17 mm |
|
Edge To Center L2 |
28 mm |
Base Height H1 |
10 mm |
|
Width & Height W1 |
20 mm |
Hole Depth T |
12 mm |
|
Set Screw SS |
M5 |
Screw To Edge LS |
8 mm |
| Additional Information | |||
|
Material Specification |
Anodized Aluminum |
Manufacturer |
JW Winco/ Otto Ganter |
|
Country of Origin |
Germany |
Weight (lbs) |
0.112500 |
|
UPC |
634529230145 |
Tariff Code |
7609.00.0000 |
|
UNSPC Code used to identify products to standardize nomenclature around the world. |
31162908 |
||
| Product Notes | |||
|
Note 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
|
|
