MSCC-25-25-SS

$196.58 ea
Quantity Price (USD)
1 $196.58 ea
10 $117.95 ea
25 $98.29 ea
50 $88.46 ea
100 Request Quote
In Production Lead Time: 1 Week or Less
Ruland MSCC-25-25-SS, 25mm x 25mm Rigid Coupling, 303 Stainless Steel, Set Screw Style with Keyway, 45mm OD, 75mm Length

PRODUCT SPECIFICATIONS

Ruland MSCC-25-25-SS is a set screw rigid coupling with 25mm x 25mm bores, 8mm x 8mm keyways, 45mm OD, and 75mm length. It has precision honed bores on to ensure bores are collinear and does not introduce misalignment or vibration into the system making it suitable for high precision servo appliactions as well as shaft to shaft connections. Forged screws test beyond DIN 912 12.9 standards to ensure maximum holding power. Tightly controlled bore tolerance of +.050mm/+.012mm is maintained. MSCC-25-25-SS is made from 303 stainless steel with hardware of like material for consistent corrosion resistance. It is machined from solid bar stock that is sourced exclusively from North American mills and is RoHS2 and REACH compliant. MSCC-25-25-SS is manufactured in our Marlborough, MA factory under strict controls using proprietary processes.

Installation Instructions

DownLoad

PRODUCT SPECIFICATIONS

Dimensions

Large Bore B1

25 mm

Small Bore B2

25 mm

Keyway K

8 mm

Keyway K2

8 mm

B1 Shaft Penetration

37.5 mm

B2 Shaft Penetration

37.5 mm

Bore Tolerance

+.050 mm / +.012 mm

Outer Diameter OD

45 mm

Length L

75 mm

Fastening Hardware

Forged Set Screw

M8

Screw Material

18-8 300 Series Stainless Steel

Hex Wrench Size

4.0 mm

Screw Finish

Bright

Seating Torque

13.6 Nm

Screw Location R

0.150 in

Number of Screws

4 ea

Performance Specifications

Torque

Rating Coming Soon

Maximum Speed

4,000 RPM

Additional Information

Material Specification

Type 303 Austenitic, Non-Magnetic Bar

Temperature

-40°F to 350°F
-40°C to 176°C

Finish Specification

Bright

Country of Origin

USA

Weight (lbs.)

1.4000

UPC

63452907690

CERTIFICATIONS/STANDARDS
ISO 9001:2008

Certified

Conflict Minerals

Compliant

RoHS2

Compliant

REACH

Compliant
