Dimensions | |||
---|---|---|---|
OG Style |
Threaded Hole |
OG VI Outside Diameter |
0,98 pulg (25 mm) |
Altura (H1) |
0,81 pulg (20.5 mm) |
Rosca (TH) |
M6 x 1,0 |
Espesor de la placa (PT) |
0,08 pulg (2 mm) |
OG VI Tapped Hole Depth |
0,24 pulg (6.1 mm) |
Performance Specifications | |||
Rango del resorte |
468 lb-pulg (82 N/mm) |
Dureza en Shore |
55A (+/- 5) |
Desviación máxima |
0,21 pulg (5,3 mm) |
Carga máxima |
96,67 lb (430 N) |
Additional Information | |||
Multipack Quantity |
5 |
Geometría del ensamblaje |
Truncated Conical |
Material del caucho |
Nitrile |
OG Metallic Body Material |
Acero Inoxidable |
OG Metallic Body Finish |
Brillante |
País de origen |
Hungría |
peso |
0.143300 |
UPC |
634529366516 |
Tariff Code |
4016.99.6000 |
UNSPC |
31162804 |
Product Notes | |||
Nota 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
