| Abmessungen | |||
|---|---|---|---|
|
OG Style |
Threaded Hole |
OG VI Outside Diameter |
2,01 zoll (51,1 mm) |
|
Höhe (H1) |
2,24 zoll (57 mm) |
Gewinde (TH) |
3/8 zoll - 16 TPI |
|
Plattendicke (PT) |
0,08 zoll (2 mm) |
OG VI Tapped Hole Depth |
0,39 zoll (9,9 mm) |
| Leistungsbeschreibungen | |||
|
Federrate |
285 lb-zoll (49,91 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
0,67 zoll (17,1 mm) |
Max. Belastung |
191 lb (849,6 N) |
| zusätzliche Information | |||
|
Dämpfergeometrie |
Conical |
Gummimaterial |
Naturkautschuk |
|
OG Metallic Body Material |
Edelstahl |
OG Metallic Body Finish |
Glänzend Poliert |
|
Herkunftsland |
Ungarn |
Gewicht (kg) |
0.220500 |
|
UPC |
634529365298 |
Tariff Code |
4016.99.6000 |
|
UNSPC |
31162804 |
||
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
||
