| Abmessungen | |||
|---|---|---|---|
|
OG Style |
Threaded Hole & Stud |
OG VI Outside Diameter |
2,01 zoll (51,1 mm) |
|
Höhe (H1) |
2,01 zoll (51 mm) |
Gewinde (TH) |
3/8 zoll - 16 TPI |
|
Plattendicke (PT) |
0,08 zoll (2 mm) |
OG VI Stud Length |
1,14 zoll (29 mm) |
|
OG VI Tapped Hole Depth |
0,39 zoll (9,9 mm) |
||
| Leistungsbeschreibungen | |||
|
Federrate |
1364,73 lb-zoll (239 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
1,00 zoll (25,4 mm) |
Max. Belastung |
682,07 lb (3034 N) |
| zusätzliche Information | |||
|
Dämpfergeometrie |
Cylindrical |
Gummimaterial |
Naturkautschuk |
|
OG Metallic Body Material |
Edelstahl |
OG Metallic Body Finish |
Glänzend Poliert |
|
Herkunftsland |
Ungarn |
Gewicht (kg) |
0.396800 |
|
UPC |
634529235324 |
Tariff Code |
4016.99.6000 |
|
UNSPC |
31162804 |
||
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
Prop 65 |
|
WARNING This product can expose you to chemicals including Soots and Nickel (metallic)
