| Abmessungen | |||
|---|---|---|---|
|
OG VI Outside Diameter |
1,18 zoll (30 mm) |
Höhe (H1) |
1,18 zoll (30 mm) |
|
Gewinde (TH) |
M8 x 1,25 |
Plattendicke (PT) |
0,08 zoll (2 mm) |
|
OG VI Stud Length |
0,79 zoll (20 mm) |
OG VI Tapped Hole Depth |
0,31 zoll (7,9 mm) |
| Leistungsbeschreibungen | |||
|
Federrate |
799,42 lb-zoll (140 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
0,30 zoll (7,6 mm) |
Max. Belastung |
237,17 lb (1055 N) |
| zusätzliche Information | |||
|
Multipack Quantity |
2 |
Dämpfergeometrie |
Cylindrical |
|
Gummimaterial |
Naturkautschuk |
OG Metallic Body Material |
Edelstahl |
|
OG Metallic Body Finish |
Glänzend Poliert |
Herkunftsland |
Ungarn |
|
Gewicht (kg) |
0.216600 |
UPC |
634529313817 |
|
Tariff Code |
4016.99.6000 |
UNSPC |
31162804 |
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
Prop 65 |
|
WARNING This product can expose you to chemicals including Soots and Nickel (metallic)
