| Abmessungen | |||
|---|---|---|---|
|
OG Style |
Threaded Stud |
OG VI Outside Diameter |
2,95 zoll (75 mm) |
|
Höhe (H1) |
3,50 zoll (89 mm) |
Gewinde (TH) |
M12 x 1,75 |
|
Plattendicke (PT) |
0,12 zoll (3 mm) |
OG VI Stud Length |
1,46 zoll (37 mm) |
| Leistungsbeschreibungen | |||
|
Federrate |
714 lb-zoll (125 N/mm) |
Shore Härte |
70A (+/- 5) |
|
Max. Ablenkung |
0,79 zoll (20,1 mm) |
Max. Belastung |
571 lb (2540 N) |
| zusätzliche Information | |||
|
Dämpfergeometrie |
Conical |
Gummimaterial |
Naturkautschuk |
|
OG Metallic Body Material |
Stahl |
OG Metallic Body Finish |
Gelb zinkchromatiert |
|
Herkunftsland |
Ungarn |
Gewicht (kg) |
0.853200 |
|
UPC |
634529363102 |
Tariff Code |
4016.99.6000 |
|
UNSPC |
31162804 |
||
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
||
