| Abmessungen | |||
|---|---|---|---|
|
OG VI Outside Diameter |
1,50 zoll (38 mm) |
Höhe (H1) |
1,26 zoll (32 mm) |
|
Gewinde (TH) |
5/16 zoll - 18 TPI |
Plattendicke (PT) |
0,08 zoll (2 mm) |
|
OG VI Stud Length |
0,63 zoll (16 mm) |
||
| Leistungsbeschreibungen | |||
|
Federrate |
645 lb-zoll (113 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
0,31 zoll (7,9 mm) |
Max. Belastung |
202 lb (900 N) |
| zusätzliche Information | |||
|
Dämpfergeometrie |
Truncated Conical |
Gummimaterial |
Silikon |
|
OG Metallic Body Material |
Edelstahl |
OG Metallic Body Finish |
Glänzend Poliert |
|
Herkunftsland |
Ungarn |
Gewicht (kg) |
0.066100 |
|
UPC |
634529364062 |
Tariff Code |
4016.99.6000 |
|
UNSPC |
31162804 |
||
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
||
