| Abmessungen | |||
|---|---|---|---|
|
OG VI Outside Diameter |
1,57 zoll (40 mm) |
Höhe (H1) |
0,79 zoll (20 mm) |
|
Gewinde (TH) |
M8 x 1,25 |
Plattendicke (PT) |
0,08 zoll (2 mm) |
|
OG VI Tapped Hole Depth |
0,31 zoll (7,9 mm) |
||
| Leistungsbeschreibungen | |||
|
Federrate |
5938,56 lb-zoll (1040 N/mm) |
Shore Härte |
40A (+/- 5) |
|
Max. Ablenkung |
0,09 zoll (2,3 mm) |
Max. Belastung |
539,54 lb (2400 N) |
| zusätzliche Information | |||
|
Multipack Quantity |
5 |
Dämpfergeometrie |
Cylindrical |
|
Gummimaterial |
Naturkautschuk |
OG Metallic Body Material |
Stahl |
|
OG Metallic Body Finish |
Gelb zinkchromatiert |
Herkunftsland |
Ungarn |
|
Gewicht (kg) |
0.639300 |
UPC |
634529359129 |
|
Tariff Code |
4016.99.6000 |
UNSPC |
31162804 |
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
||
