| Abmessungen | |||
|---|---|---|---|
|
OG VI Outside Diameter |
0,39 zoll (10 mm) |
Höhe (H1) |
0,79 zoll (20 mm) |
|
Gewinde (TH) |
M4 x 0,7 |
Plattendicke (PT) |
0,05 zoll (1,2 mm) |
|
OG VI Tapped Hole Depth |
0,16 zoll (4 mm) |
||
| Leistungsbeschreibungen | |||
|
Federrate |
85,65 lb-zoll (15 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
0,20 zoll (5,0 mm) |
Max. Belastung |
16,41 lb (73 N) |
| zusätzliche Information | |||
|
Multipack Quantity |
5 |
Dämpfergeometrie |
Cylindrical |
|
Gummimaterial |
Naturkautschuk |
OG Metallic Body Material |
Edelstahl |
|
OG Metallic Body Finish |
Glänzend Poliert |
Herkunftsland |
Ungarn |
|
Gewicht (kg) |
0.044100 |
UPC |
634529367070 |
|
Tariff Code |
4016.99.6000 |
UNSPC |
31162804 |
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
||
