| Abmessungen | |||
|---|---|---|---|
|
OG VI Outside Diameter |
3,94 zoll (100 mm) |
Höhe (H1) |
2,95 zoll (75 mm) |
|
Gewinde (TH) |
M16 x 2,0 |
Plattendicke (PT) |
0,12 zoll (3 mm) |
|
OG VI Stud Length |
1,61 zoll (41 mm) |
||
| Leistungsbeschreibungen | |||
|
Federrate |
2940,73 lb-zoll (515 N/mm) |
Shore Härte |
55A (+/- 5) |
|
Max. Ablenkung |
0,74 zoll (18,8 mm) |
Max. Belastung |
2167,16 lb (9640 N) |
| zusätzliche Information | |||
|
Dämpfergeometrie |
Cylindrical |
Gummimaterial |
Naturkautschuk |
|
OG Metallic Body Material |
Edelstahl |
OG Metallic Body Finish |
Glänzend Poliert |
|
Herkunftsland |
Ungarn |
Gewicht (kg) |
2.433700 |
|
UPC |
634529235034 |
Tariff Code |
4016.99.6000 |
|
UNSPC |
31162804 |
||
| Produkthinweise | |||
|
Anmerkung 1 |
Performance ratings are for guidance only. The user must determine suitability for a particular application. |
Prop 65 |
|
WARNING This product can expose you to chemicals including Soots and Nickel (metallic)
