DSD - Set Screw

Features

  • High torque
  • Balanced design for high RPM
  • Low Inertia
  • No maintenance
  • High torsional stiffness
  • Constant velocity
  • Long life
  • Zero backlash
  • RoHS2 and REACH Compliant
  • Maximum speed: 10,000 RPM
  • Bore tolerance: +.001"/-.000"
  • Temperature Range: -10°F to 200°F

Products

View as Grid Table

Items 1-12 of 85

Page
per page
Set Descending Direction
  1. Ruland DSD10-2-2-A, Double Disc Coupling
    DSD10-2-2-A
    In stock
    Ruland DSD10-2-2-A, 1/8" x 1/8" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  2. Ruland DSD10-3-2-A, Double Disc Coupling
    DSD10-3-2-A
    In stock
    Ruland DSD10-3-2-A, 3/16" x 1/8" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  3. Ruland DSD10-3-3-A, Double Disc Coupling
    DSD10-3-3-A
    In stock
    Ruland DSD10-3-3-A, 3/16" x 3/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  4. Ruland DSD10-4-2-A, Double Disc Coupling
    DSD10-4-2-A
    In stock
    Ruland DSD10-4-2-A, 1/4" x 1/8" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  5. Ruland DSD10-4-3-A, Double Disc Coupling
    DSD10-4-3-A
    In stock
    Ruland DSD10-4-3-A, 1/4" x 3/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  6. Ruland DSD10-4-4-A, Double Disc Coupling
    DSD10-4-4-A
    In stock
    Ruland DSD10-4-4-A, 1/4" x 1/4" Double Disc Coupling, Aluminum, Set Screw Style, 0.590" OD, 0.937" Length
  7. Ruland DSD12-3-3-A, Double Disc Coupling
    DSD12-3-3-A
    In stock
    Ruland DSD12-3-3-A, 3/16" x 3/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
  8. Ruland DSD12-4-3-A, Double Disc Coupling
    DSD12-4-3-A
    In stock
    Ruland DSD12-4-3-A, 1/4" x 3/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
  9. Ruland DSD12-4-4-A, Double Disc Coupling
    DSD12-4-4-A
    In stock
    Ruland DSD12-4-4-A, 1/4" x 1/4" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
  10. Ruland DSD12-5-3-A, Double Disc Coupling
    DSD12-5-3-A
    In stock
    Ruland DSD12-5-3-A, 5/16" x 3/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
  11. Ruland DSD12-5-4-A, Double Disc Coupling
    DSD12-5-4-A
    In stock
    Ruland DSD12-5-4-A, 5/16" x 1/4" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
  12. Ruland DSD12-5-5-A, Double Disc Coupling
    DSD12-5-5-A
    In stock
    Ruland DSD12-5-5-A, 5/16" x 5/16" Double Disc Coupling, Aluminum, Set Screw Style, 0.750" OD, 1.189" Length
